Dia 2inch Thick 0.5mm La3ga5sio14 Single Langasite Crystal LGS Substrate

Name: Dia 2inch Thick 05mm La3ga5sio14 Single Langasite Crystal LGS Substrate
Brand: Crystro
Price: 1 USD

China Dia 2inch Thick 0.5mm La3ga5sio14 Single Langasite Crystal LGS Substrate wholesale

Brand Name : Crystro

Model Number : CR210519-01

Certification : SGS/COC

Place of Origin : China

MOQ : 1pc

Price : Negotiable

Payment Terms : T/T, Western Union, MoneyGram, Paypal

Supply Ability : 2000pcs per month

Delivery Time : 2-4 weeks

Packaging Details : Transparent clean box

Type : Dia 2inch Thick 0.5mm Langasite Single Crystal LGS Substrate

Diameter : 50.8mm

Thickness : 0.5mm/1mm

Ra : <0.5nm

Material : La3Ga5SiO14

Growth Method : Czochralski

Warranty : 1 year

Color : Faint Yellow

Contact Now

Dia 2inch Thick 0.5mm Langasite Single Crystal LGS Substrate

Lanthanum gallium silicate ( La₂Ga₅SiO₁₄ ) is a phenomenal invention. Though langasite was initially developed as a laser crystal, it revealed a remarkable combination of piezoelectric qualities, which opened up new opportunities to use the LGS crystal in radio frequency devices. The main applications of langasite crystals now is SAW filters and SAW resonators. Experts agree that LGS is the best choice for high-efficiency broad band frequency devices because it possesses exceptional frequency-temperature characteristics, a very high index of electromechanical coupling and unparalleled Q-factor.

Crystro's LGS crystal has High thermal stability,low equivalent series resistance ratio and electro-mechanical coupling coefficient is 3-4 times than quartz.

Anhui Crystro participate in the kinds exhibitions every year: Laser World of Photonics Munich, Shanghai, Photonics West in San Francisco, CIOE in Shenzhen, etc.

Main Properties:

Point group	32
Airborne group	P32I
specific resistance	4.0×1012Ω/cm-1
Thickness	0.13-0.5mm
Diameter	50mm
Length	90-100mm
Melting point	1470℃
Density	5.67g/cm3
Mohs hardness	5.5
Thermal expansion coefficient	aa=16×10-6/K, ac=4×10-6/K
Photo damage threshold	670MV/cm2
Cell Parameters	a=b=0.8162nm,c=0.5087nm
Dielectric constant	ε11=18.27
Dielectric constant	ε33=55.26
Electro-optical coefficients	γ11=2.3×10-12m/V
Electro-optical coefficients	γ33=1.8×10-12m/V
Piezoelectric strain constant	d11=6.3
(10-12)C/N	d14=-5.4
Phase velocity,m/s	2750～2850
Electromechanical coupling coefficient, K[ %]	0.28～0.46
Solubility	None
Coefficient of thermal expansion	α11=5.15×10-6K-1
Coefficient of thermal expansion	α33=3.65×10-6K-1

Features:

High damage threshold
Good optical rotation
Can withstand high and low temperature changes
Stable physical and chemical properties
High electromechanical coupling coefficient (3 times of quartz)
Low equivalent series resistance
Applications:
electro-optic Q-switch
SAW device
BAW device
Sensor
High power high repetition rate all solid state laser
High and low temperature change laser

DOCUMENT:
LGS Cryatal.pdf

Dia 2inch Thick 0.5mm La3ga5sio14 Single Langasite Crystal LGS Substrate

Product Tags:

Dia 2inch Thick 0.5mm La3ga5sio14 Single Langasite Crystal LGS Substrate Images
